VISUALYZE® PRODUCT LINE
Built for your
imaging system.
Choose a standard scope configuration, then pair it with a Visualyze® video processing unit or tablet. Mechanical and system features can be tailored to your application.
01 / IMAGE CAPTURE
Visualyze® scopes
Videoscopes with integrated illumination. Seven standard models span flexible and semi-rigid behavior, with 400 × 400 or 720 × 720 native sensor resolution.
The listed maximum video output is 1,000 × 1,000 pixels when used with Visualyze® video processing hardware. Almost all mechanical specifications can be customized.
| Model | Behavior | D1 outer diameter | Native sensor pixels | Min. bend radius | Documents & inquiry |
|---|---|---|---|---|---|
| ENA-10420-AS | Semi-rigid | 1.54 mm | 400 × 400 | 50 mm | |
| ENA-10468-AS | Flexible | 0.85 mm | 400 × 400 | 6 mm | |
| ENA-10448-AS | Flexible | 0.89 mm | 400 × 400 | 6 mm | |
| ENA-10449-AS | Flexible | 0.98 mm | 400 × 400 | 6 mm | |
| ENA-10453-AS | Semi-rigid | 1.05 mm | 400 × 400 | 30 mm | |
| ENA-10460-AS | Flexible | 1.40 mm | 400 × 400 | 6 mm | |
| ENA-10467-AS | Semi-rigid | 1.54 mm | 720 × 720 | 50 mm |
D1 refers to the dimension shown in the scope brief. Discuss your required configuration, current availability and specifications with our team.
02 / VIDEO PROCESSING · ENA-10570-AS
Visualyze®
Video Processing Unit
A USB 3.0 and HDMI module with recording capability, compatible with all Visualyze® scope models.
Two outputs
Simultaneous USB 3.0 UVC and HDMI video.
External recording
Still images and video to an attached USB flash drive.
Integration ready
External control via service port; main PCB available for integration into customer controllers.
Automatic scene control
Auto-Global-Gain® adjusts exposure, gain and light.
03 / DISPLAY & RECORDING · ENA-10660-AS
Visualyze® Tablet
A custom-made touchscreen system for Visualyze® scopes with internal image and video recording.
Integrated display
10.4-inch capacitive touchscreen with on-device viewing and replay.
Simultaneous video
HDMI and USB 3.0 outputs alongside the built-in display.
Internal capture
Record still images and live video; copy files to an external USB drive.
Tailored interface
Software and user interface can be branded and customized for the customer.
CUSTOM IMAGE EMBEDDING
Make the system
part of your device.
Scope shafts, diameter, stiffness, cable length, handle location and functionality can be developed around your requirements.
Explore custom capabilities ↗
